Highland Ridge RV Mesa Ridge S-Lite Travel Trailer RVs For Sale

Previous
Next
1 of 8

The Highland Ridge RV Mesa Ridge S-Lite travel trailers are great for families or couples who are looking for a lightweight unit to tow! They may be light in weight, but they will still hold up to whatever adventure you throw their way with the Tuffshell walls, a thermal seal, and a PVC roofing membrane making it one of the strongest roofs in the business!



There is a variety of space-maximizing floorplans to choose from with many convenient features included like a mandatory Customer Convenience package. An oversized pass-through storage area comes with motion lighting so you can easily see all of your items at night. A laundry chute in the bedroom keeps your dirty clothes in one place, and the residential vinyl flooring throughout is kid and pet friendly!



It will be easy to tow a Highland Ridge RV Mesa Ridge S-Lite travel trailer!

  • Mesa Ridge S-Lite 212FB

    Mesa Ridge S-Lite 212FB Floorplan Image

    Take a Virtual Tour

    Highland Ridge Mesa Ridge S-Lite travel trailer 212FB highlights: Front Private ... more about Mesa Ridge S-Lite 212FB

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 3
    Slides 1
    Length 23 ft 3 in
    Ext Width 8 ft 1 in
    Ext Height 11 ft 1 in
    Int Height 6 ft 9 in
    Interior Color Graystone
    Hitch Weight 505 lbs
    GVWR 6400 lbs
    Dry Weight 4880 lbs
    Cargo Capacity 1520 lbs
    Fresh Water Capacity 45 gals
    Grey Water Capacity 29 gals
    Black Water Capacity 29 gals
    Tire Size ST205/75R14'D
    Furnace BTU 35000 btu
    Available Beds Queen
    Refrigerator Type 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Number of Awnings 1
    LP Tank Capacity 30 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric
    AC BTU 15000 btu
    TV Info LR Smart HDTV
    Awning Info 12' Power with LED Lights
    Axle Count 2
    Number of LP Tanks 2
    Shower Type Radius

    Similar Floorplans

  • Mesa Ridge S-Lite 225CK

    Mesa Ridge S-Lite 225CK Floorplan Image

    Take a Virtual Tour

    Highland Ridge Mesa Ridge S-Lite travel trailer 225CK highlights: Front Queen ... more about Mesa Ridge S-Lite 225CK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 1
    Length 27 ft 4 in
    Ext Width 8 ft 1 in
    Ext Height 11 ft
    Int Height 6 ft 10 in
    Interior Color Graystone
    Hitch Weight 550 lbs
    GVWR 6500 lbs
    Dry Weight 5090 lbs
    Cargo Capacity 1410 lbs
    Fresh Water Capacity 45 gals
    Grey Water Capacity 29 gals
    Black Water Capacity 29 gals
    Tire Size ST205/75R14'D
    Furnace BTU 35000 btu
    Available Beds Queen
    Refrigerator Type 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Number of Awnings 1
    LP Tank Capacity 30 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric
    AC BTU 15000 btu
    TV Info LR Smart HDTV
    Awning Info 19' Power with LED Lights
    Axle Count 2
    Number of LP Tanks 2
    Shower Type Tub/Shower Combo
  • Mesa Ridge S-Lite 252RB

    Mesa Ridge S-Lite 252RB Floorplan Image

    Take a Virtual Tour

    Highland Ridge Mesa Ridge S-Lite travel trailer 252RB highlights: Dual Entry ... more about Mesa Ridge S-Lite 252RB

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 1
    Length 30 ft 9 in
    Ext Width 8 ft 1 in
    Ext Height 11 ft 1 in
    Int Height 6 ft 9 in
    Interior Color Graystone
    Hitch Weight 715 lbs
    GVWR 7500 lbs
    Dry Weight 5440 lbs
    Cargo Capacity 1345 lbs
    Fresh Water Capacity 45 gals
    Grey Water Capacity 58 gals
    Black Water Capacity 29 gals
    Tire Size ST205/75R14D
    Furnace BTU 35000 btu
    Available Beds Queen
    Refrigerator Type 12V
    Refrigerator Size 10 cu ft
    Cooktop Burners 3
    Number of Awnings 1
    LP Tank Capacity 30 lbs
    Water Heater Capacity 6 gal
    Water Heater Type Gas/Electric
    AC BTU 15000 btu
    TV Info LR Smart HDTV
    Awning Info 20' Power with LED Lights
    Axle Count 2
    Number of LP Tanks 2
    Shower Type Radius

    Similar Floorplans

Mesa Ridge S-Lite Features:

Standard Features (2023)



Exterior Equipment

  • 5/8" main floor decking
  • Door side spray port
  • Exterior grill/griddle quick connect port
  • Flexible LP lines
  • Foldable grab handle
  • Fully-walkable roof
  • In-frame battery rack
  • Magnetic baggage door catches
  • Oversized pass-through storage with motion lighting
  • PVC roofing membrane (limited lifetime warranty)
  • Rain guttering with molded drip spouts
  • Rear observation camera prep
  • Safety bumper with drain hose carrier and end caps
  • Self-adjusting electric brakes
  • Side camera prep marker lights
  • Solid swing-down entry steps
  • Thermal Seal- enclosed, insulated and heated underbelly with fully insulated roof with a PVC roofing membrane
  • Tinted safety-glass windows throughout
  • TuffShell™ - vacuum bonded laminated construction, reinforced with heavy-duty fiberglass and welded aluminum frames

Interior Equipment

  • 60" x 80" residential queen bed with storage drawers below
  • 75 lb. ball bearing drawer guides
  • 81" interior height
  • Cable and satellite prep
  • Electrical outlets and USB ports in master bedroom
  • Flush floor slides with residential vinyl flooring
  • Hardwood cabinet doors
  • Kitchen sink covers
  • Laundry chute in bedroom
  • LED interior lighting
  • Medicine cabinet
  • Powered 12V bathroom vent
  • Range hood
  • Residential high-rise faucet
  • Roller blackout night shades
  • Soft closing foot flush toilet
  • Stainless steel single basin under-mount kitchen sink
  • Tri-fold sofa (select models)

Customer Convenience Package (Mandatory)

  • 15,000 BTU roof mounted A/C
  • 2-30 lb. LP bottles
  • 3-burner range with 17" oven and flush mount glass cover
  • 10 cu. ft. 12V refrigerator
  • Dome style digital TV antenna with Wi-Fi prep
  • Enclosed exterior docking station with black tank flush
  • Entrance door with screen door, window and magnet door catch
  • EZ-store detachable cord
  • Gas/electric water heater
  • JBL® Aura Cube stereo with Bluetooth® and miZONE™ technology
  • JBL® Premium indoor and outdoor multizone speakers
  • Microwave
  • Molded front cap with LED lighting and stoneguard protection
  • Nitrogen filled radial tires with aluminum rims
  • Pop up wireless and USB charger in bedroom
  • Power awning with LED lighting
  • Power tongue jack
  • Pressed membrane countertops
  • Rear roof access ladder
  • Smart HDTV

Options

  • Xtend Solar I Package (200 watt solar panel with 30 amp solar controller)
  • Xtend Solar II Package (2-200 watt solar panels with 30 amp solar controller and 1800 watt inverter)
  • 50 amp service with 2nd A/C (232MD, 252RB, 262RL, 282RL)
  • 8 cu. ft. gas/electric refrigerator
  • Wi-Fi router
  • Electric stabilizer jacks
  • Theater seating ipo L-sofa (212FB only)
  • Theater seating ipo tri-fold sofa (N/A 241BH)
  • Free standing table with 2 chairs and bench (N/A 212FB, 232MD)
  • Free standing table with 4 chairs (N/A 212FB, 232MD)

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Due to the current environment, our features and options are subject to change due to material availability.

Manu-Facts:

Highland Ridge RV Logo

For us, it’s all about solving the problems RVers encounter every day, building the RVer’s RV. Through deliberate design, year after year, we come up with creative RV solutions that make time at camp a little easier, and a lot more comfortable. You’ll enjoy time spent in your home away from home and own the outdoors with a Highland Ridge RV.



It all started in March of 2014 when Jayco purchased assets of Open Range RV. Today, Highland Ridge RV is a subsidiary of Jayco and operates its own manufacturing facilities, service and warranty group, sales team, management and leadership teams. We’re proud to be associated with a company that shares our same commitment to great quality, integrity, vision and values.



The Highland Assurance is our commitment to quality and deliberate design. It’s building RVs that are rooted in the experiences and suggestions of RVers who know what they like, what works and what doesn’t. Most importantly, it’s about assuring you an enjoyable and trouble-free experience. From the factory to the campground, we’ve got your back.
